ProStructures

Parametric steel and concrete modeling

• Model reinforced concrete and structural steel elements with parametric intelligence

• Support multiple national and international design codes

• Use standard and customizable objects, including beams, columns, slabs, walls, foundations, stair towers, handrails, ladders, bracing, portal frames, platforms, and walkways

• Apply reinforcement using face-based modeling that automatically adapts to changes in concrete geometry

• Modify steel and concrete with features such as drill holes, bolts, notches, polycuts, diagonal cuts, and reinforcement adjustments

• Enable user-defined reinforcement to support rebar of any shape or complexity

• Leverage templates and styles to maintain standards, consistency, and reuse across projects

Documentation

• Quickly extract fabrication, erection, placing, and general arrangement drawings

• Automatically update drawings based on changes to the 3D model

• Customize drawing output based on user-defined detail styles and preferences

• Generate bar bending schedules, part lists, and bills of materials (BOM) in single or batch process.

• Create numerical control (NC) data for steel fabrication and digital deliverables for rebar placement

Interoperability

• Share structural data seamlessly across design and fabrication workflows

• Exchange information with disciplines including architectural, plant, process, HVAC, and building services

• Reference models from OpenBuildings Designer, OpenBridge Modeler, and MicroStation

• Export to industry formats such as IFC, ISM, iModels, 3D PDF, SDNF, and CIS/2

• Integrate with Bentley applications (STAAD, RAM) as well as third-party software, ERP systems, and CNC machines

Integrate modeling and documentation work

• Support ProjectWise® managed workspaces

• Share models directly from the desktop as iModels or 3D PDFs

• Review project details and monitor performance with real-time visibility

• Access personalized learning, communities, and project resources

• Coordinate effectively with connected teams to accelerate project delivery

Processor:

• Intel or AMD Processor 2.0 GHz or greater

Operating System:

• Windows 10 (64-bit), Windows 8 (64-bit), Windows 8.1 (64-bit), Windows 7 (64-bit), Windows Server 2008 R2 SP1 (64-bit), Windows Server 2012 (64-bit)

Memory Minimum:

• 4 GB minimum, 16 GB recommended.

Disk Space:

• 25 GB minimum

Video:

• Graphics card supported by DirectX 9.0c. 512 megabytes of video RAM or higher.
