OpenPlant Isometrics Manager

Interoperability

• Generate PCF files to pass data to existing fabrication systems

• Produce isometrics from OpenPlant, AutoPLANT, and AutoPIPE

• Create isometric deliverables in DGN or DWG formats

• Works with OpenPlant and AutoPLANT Central Management

• Use a common setup and configuration through ProjectWise managed workspaces

• Store similar isometrics in a central location

• Navigate between plant models and generated isometrics

• Examine piping components from the same model using different views

Design model component information

• Perform intelligent queries against components to find those with identical information to 3D design models

• View relevant data available in other areas of the design and construction process

Isometric production

• Separate isometric production from piping design applications

• Control isometric drawing generation by using status settings

• Generate production log files for piping isometric drawings

Usability

• Easy-to-use interface, with no need to manage complex switches, file structures, or settings

• Query tools to search piping components by line number or attributes

• Project-driven drawing output and bill of material definitions

Isometrics drawing and style configuration

• Intelligent piping isometric drawings include graphics and piping data

• Easy-to-configure isometrics styles—no need to remember switches

• User-configurable drawing layouts and reporting

• Simple isometrics symbols creation using MicroStation cells

• Fully configurable bill of material layout

• Customized drawing attributes for additional pipeline information

ProjectWise integration

• Manage multiple projects from a single model or data source

• Include metadata with project documents

• Save user queries locally or to ProjectWise for team access

• Edit isometric name expression

• Populate ProjectWise document attributes when an isometric drawing is posted to ProjectWise

• Browse element information or specific components or sets of components

Processor:

• Intel or AMD Processor 2.5 GHz or greater.

Operating System:

• Windows 11 or 10 (64 bit)/ Windows 11 (24H2) or Windows 10 (21H2), Windows Server 2019, Windows Server 2022 (64 bit).

Memory Minimum:

• 16 GB minimum, 32 GB recommended.

Disk Space:

• 25 GB minimum, 25-42 GB depending on additional installations.

Video:

• 1024 MB of video RAM minimum. 

Screen Resolution:

• 1920 x 1080 pixels minimum.
