    SewerGEMS

    Responsible sewer management

Modeling Software for Sanitary and Combined Sewers

If building and preparing your sewer models feels like a never-ending task, SewerGEMS software is for you.

SewerGEMS streamlines the modeling process, so that you have more time for solving wastewater engineering problems, such as improving capacity and limiting sewer overflows, which ultimately enable utilities to comply with sewer regulations set by regulatory agencies.

Read More +
    • Allocate and estimate sanitary loads
    • Allocate and estimate stormwater loads
    • Analyze hydraulics and combined sewer overflows
    • Analyze hydrogen sulfide formation
    • Analyze inlet capacities
    • Build and manage hydraulic models
    • Design and analyze culverts
    • Design and analyze low impact development controls
    •  Design and analyze pond and outlets
    • Design stormwater systems
    • Simulate water quality
Capabilities
  • Allocate and estimate sanitary loads

    • Apply hydrographs, patterned loads, and unit loads using a comprehensive and customizable engineering library. Use the LoadBuilder module to leverage consumption, flow monitoring, land use, or census data in your GIS to automatically estimate and import sanitary loads for your sewer model.​
  • Allocate and estimate stormwater loads

    • Load models with wet weather runoff flows derived from precipitation using the built-in rainfall distributions or user-defined rainfall events. Runoff flows are computed using the most appropriate runoff method for the project.​​
  • Analyze hydraulics and combined sewer overflows

    • Easily switch among multiple solvers according to the type of system you are analyzing: Saint Venant equations, convex/gradually varied flow solver (steady-state analysis for extreme flow conditions and extended period simulations), and rational/gradually varied flow solver.​
  • Analyze hydrogen sulfide formation

    • Identify areas in your network that are at risk of damage from hydrogen sulfide (H2S) formation, which can lead to potential collapses if not addressed. Produce average concentration runs, display result maps of the network, and compare H2S formation according to various conditions such as temperature.​
  • Analyze inlet capacities

    • Calculate the proportion of stormwater runoff that will enter an inlet versus the proportion that will be carried downstream in a gutter or pond on the road surface. Quickly confirm that the spread of flow in a gutter doesn't exceed design requirements.​
  • Build and manage hydraulic models

    • Jumpstart the model-building process and manage your model effectively, so that you can focus on making the best engineering decisions. Leverage and import virtually any external data format, which maximizes ROI on geospatial and engineering data, and automate terrain extraction and node allocation.​
  • Design and analyze culverts

    • Select from a library of standard culvert shapes, materials, and entrance conditions, then compute culvert headwater and tailwater elevations using calculation methodologies outlined in Hydraulic Design Series Number 5 from the U.S. Federal Highway Administration.
  • Design and analyze low impact development controls

    • Model the effect that low impact development controls have in retaining runoff before it enters the stormwater system.​​
  • Design and analyze pond and outlets

    • Leverage PondMaker's guiding process through the confusing maze of pond design steps by following the step-by-step process that provides constant feedback on how the design is progressing. Set the maximum outflow rate, estimate storage, and check the outlet design and final design.​
  • Design sanitary sewers

    • Minimize capital investments by simply entering your design restrictions: velocities, slopes, cover depths, and pipe and manhole matching offsets. SewerCAD/SewerGEMS recommends the most cost-effective pipe sizes and invert elevations, avoiding unnecessary pipe trench excavation, while meeting design restrictions.​​
  • Design stormwater systems

    • Minimize capital investments by simply entering your design restrictions: velocities, slopes, cover depths, and pipe and inlet matching offsets. The software product recommends the most cost-effective pipe sizes and invert elevations, avoiding unnecessary pipe trench excavation, while meeting design restrictions.​
  • Simulate water quality

    • Simulate the generation, inflow, and transportation and treatment of any number of user-defined pollutants, such as total suspended solids or heavy metals.
